QCA9558+QCA8337 uboot下面网口好用,进入系统后网口就不好用了,网口不通

cloudq
帖子: 46
注册: 周五 3月 18, 2016 8:43 am

QCA9558+QCA8337 uboot下面网口好用,进入系统后网口就不好用了,网口不通

帖子cloudq » 周日 8月 27, 2017 4:33 pm

QCA9558+QCA8337 uboot下面网口好用,进入系统后网口就不好用了,网口不通,如何查找原因?



Device Info
Version: SuperWRT Boot 1.3.3-g5a7c57f1-dirty (Jun 19 2017 - 15:47:47)
CPU: QCA955x - Scorpion 1.0
Flash: 16 MB (Flash ID: c22018 / Erase Size: 4k)
DRAM: 128 MB
Frequency: CPU 720MHz / RAM 600MHz / AHB 240MHz
SBI Info: 9557/mcpcloud@126.com/2017-08-27
Device UID: none
WLAN0 info: cal:0xff1000, mac:0xff0000 (ff:ff:ff:ff:ff:ff)
WLAN1 info: cal:0xff5000, mac:0xff0006 (ff:ff:ff:ff:ff:ff)
MAC: 02:54:65:72:72:61
Firmware: FW/std/0.5.15/qca/qca9k/aa57e3647b
Custom(/License):
Partions:
0x00000000-0x0001c000[0x0001c000] uboot
0x0001c000-0x00020000[0x00004000] SBI
0x00020000-0x00b60000[0x00b40000] firmware
0x00b60000-0x00f70000[0x00410000] udata
0x00f70000-0x00f80000[0x00010000] elog
0x00f80000-0x00fa0000[0x00020000] config
0x00fa0000-0x00fc0000[0x00020000] config2
0x00fc0000-0x00fe0000[0x00020000] custom
0x00fe0000-0x00ff0000[0x00010000] DTB
0x00ff0000-0x01000000[0x00010000] CAL


SuperWRT Boot 1.3.3-g5a7c57f1-dirty (Jun 19 2017 - 15:47:47)

QCA955x - Scorpion 1.0

DRAM: 128 MB
Flash: 16 MB (c22018)
Using default environment

Frequency: CPU 720MHz / RAM 600MHz / AHB 240MHz
Bootstrap Config: 0x00031c5c
SuperWRT Board Info(0x9f01c000):
9557/mcpcloud@126.com/2017-08-27
WLAN0 info: cal:0x9fff1000, mac:0x9fff0000
Device UID: none
GPIO: reset(-1/L), system(-1/L)
In: serial
Out: serial
Err: serial
Net: (02:54:65:72:72:61) S17 eth0
Set 0x18116290 = 0x458a214f
Hit 'c' or 'Ctrl+c' to stop autoboot: 1
Net Command waiting: 2
Try eth1 first.
dup 1 speed 1000

config: Config magic check error!
config2: Config magic check error!
## Booting image at 9f020000 ...
## Booting image at 9f020000 ...
Magic: ffffffff
Bad Magic Number
Failed to boot.
Starting httpd to update firmware...
Try eth1 first.
starting httpd server eth0 192.168.17.1
Alloc 192.168.17.3 to f0:c8:50:73:05:f1
HTTP: G /
HTTP: G /style.css
Alloc 192.168.17.9 to 5c:a8:6a:f7:b0:c4
HTTP: P /
Store POST at 0x801C0000
#######################################
#######################################
#######################################
